Verfügbarkeit: ca. 13 Wochen Lieferzeit
| Case | E15 |
| Chip technology | Standard recovery |
| Country of origin | Brazil |
| Current (A) | 240A |
| Dimensions (LxWxH) | 190SW32M16 |
| Features | Reverse voltages up to 1800 V Hermetic metal case with glass insulator Threaded stud ISO M16 x 1,5 SKN / SKR 240/04 ... /16 also available with threaded stud 3/4 - 16 UNF (e.g. SKR 240/12 UNF) SKR: cathode to stud |
| Housing | Stud Screw Fit |
| Legacy part number | 2236831 |
| Product line | Stud Screw Fit |
| Product Status | In Production |
| Surge current (A) | 6000A |
| Technology | Diodes |
| Typical applications | All-purpose mean power rectifier diodes Cooling via heatsinks Non-controllable and half-controllable rectifiers Free-wheeling diodes Recommended snubber network: R<sub>C</sub>: 0,5µF, 30 ? (P<sub>R</sub> = 2W), R<sub>P</sub> = 50 k? (P<sub>R</sub> = 20 W) |
| Voltage (V) | 1600V |
