Verfügbarkeit: ca. 13 Wochen Lieferzeit
| Case | E17 |
| Chip technology | Standard recovery |
| Country of origin | Brazil |
| Current (A) | 400A |
| Dimensions (LxWxH) | 230SW41M24 |
| Features | Reverse voltages up to 3000 V Hermetic metal case with glass insulator with extra long creepage distances Threaded stud ISO M24 x 1,5 SKN: anode to stud |
| Housing | Stud Screw Fit |
| Legacy part number | 2172660 |
| Product line | Stud Screw Fit |
| Product Status | In Production |
| Surge current (A) | 9000A |
| Technology | Diodes |
| Typical applications | High voltage rectifier diode, especially for traction applications Cooling via heatsinks Non-controllable and half-controllable rectifiers Free-wheeling diodes Recommended snubber network: R<sub>C</sub>: 1 µF, 20 ? (P<sub>R</sub> = 2 W), R<sub>p</sub> = 25 k? (P<sub>R</sub> = 20 W) |
| Voltage (V) | 1800V |
